The CoffeeGenius BWT Bestmax PREMIUM – WATER FILTRATION SYSTEM – Cartridges

BWT Bestmax PREMIUM Water Filtration System

BWT Bestmax by the flavour experts, it’s a unique filter system for PREMIUM water specially developed for coffee. It offers reliable limescale protection and water with top sensory characteristics, this premium BWT bestmax has patented Magnesium Technology, with mineralization for higher magnesium content ensures optimum extraction results for coffee

It’s simple to instal via universal BWT besthead FLEX connection technology and space-​saving design that is very easy to handle.

BWT  bestmax PREMIUM is an innovative filter system for optimizing water especially for all hot beverages from coffee and vending machines. This filter reduces all undesirable components such as limescale, particles, off-​flavours such as chlorine and organic compounds from the raw water.

As a pioneering innovation, this filter also features BWT Magnesium Technology, which enriches the water with valuable magnesium in exchange for calcium. In addition to effective limescale protection, BWT bestmax PREMIUM ensures outstanding results for hot beverages.

Technical advantages of BWT bestmax PREMIUM at a glance:

• 5-​stage filtration
• Reliable protection against limescale for machines
• Ideal mineralization for higher magnesium content
• Activated charcoal fleece for consistently crystal-​clear water
• Filtration, also of bypass water
• Ease of handling when replacing the filter
• Horizontal or vertical installation



Technical details



BWT bestmax PREMIUM type	S	V	M	XL	2XL
Connection thread (in/out); (1)	variable	variable	variable	variable	variable
Inlet pressure, min. – max. in bar	2–8	2–8	2–8	2–8	2–8
Water temperature, min. – max. in °C	4–30	4–30	4–30	4–30	4–30
Ambient temperature, min. – max. in °C	4–40	4–40	4–40	4–40	4–40
Total height without bracket in mm, approx.	360	420	475	502	580
Total height with bracket in mm, approx.	385	445	500	527	600
Connection height in mm	306	366	421	448	520
Distance to floor in mm	65	65	65	65	65
Installation length in mm	125	125	125	125	125
Ø filter cartridge in mm	88	110	130	147	185
Weight in kg, approx. (dry/wet)	0.9/1.5	2.3/3.2	2.8/4.2	4.0/6.0	7.8/11.0
Order no. of filter cartridge	FS22P00A00	FS23P00A00	FS24P00A00	FS28P00A00	FS30P00A00
